Bosch EBike Drive Unit Mounting Plate – Classic
Ursprünglicher Preis war: 17,90 €12,53 €Aktueller Preis ist: 12,53 €.
- Qualität, auf die Sie zählen können
- Zufriedenheit garantiert
- Kaufen Sie mit Vertrauen ein, wir garantieren Qualität.
- Online-Hilfe, immer nur eine Nachricht entfernt.
The original aluminum mounting plate for mounting the Bosch Classic Line drive unit for all e-bikes from 2010 to 2013 or 2014.
The mounting plate is required if this is defective, for example, or should be replaced for optical reasons.
Mounting notice:
Please note that the drive unit mounting plate consists of 3 parts.
- 1x Bosch Classic eBike mounting plate
- 2x Bosch M6x20 – T30 Torx screws
- 3x Bosch M8 expansion sleeves – Torx T40
The expansion sleeves expand during the assembly of the drive unit and must be replaced after disassembly. If you use the old expansion sleeves again, there is a risk of breakage and thus an increased risk of accidents.
| Bosch System: | Bosch Classic Plus Line |
| Manufacturer: | Bosch |
| Item: | Bosch E-Bike mounting plate aluminium for drive unit – Classic |
| Scope of delivery: | 1x mounting plate for Classic & Classic+ drive unit |
| Maker’s ref. no.: | 127015922 |
